光強計

Item #	PM100A	PM100D	PM100USB	PM200	PM400	PM320E
(Click Photo to Enlarg	/	/	/	/	/	/
描述	緊湊型功率計表頭，機械指針和圖形液晶顯示	緊湊型光功率和能量計表頭，數字4英寸液晶顯示器	用于C-系列傳感器的USB功率和能量計接口	觸摸屏功率計和能量計表頭, 5.7" 彩色 LCD	光功率能量計表頭，投射電容式觸摸屏	雙通道臺式功率和能量計控制臺
價格	￥11,108.10	￥12,243.00	￥7,666.78	￥17,274.00	￥11,571.30	￥25,571.00
Description	Analog Power Meter Console	Digital Power and Energy Meter Console	USB Power and Energy Meter Interface	Touchscreen Power and Energy Meter Console	Touchscreen Power and Energy Meter Console with Multi-Touch	Dual-Channel Benchtop Power and Energy Meter Console
Compatible Sensors	Photodiode and Thermal	Photodiode, Thermal, and Pyroelectric
Housing Dimensions (H x W x D)	7.24" x 4.29" x 1.61" (184 mm x 109 mm x 41 mm)	7.09" x 4.13" x 1.50" (180 mm x 105 mm x 38 mm)	3.67" x 2.38 " x 1.13" (93.1 mm x 60.4 mm x 28.7 mm)	6.70" x 4.93" x 1.48" (170.2 mm x 125.1 mm x 37.5 mm)	5.35" x 3.78" x 1.16" (136.0 mm x 96.0 mm x 29.5 mm)	4.8" x 8.7" x 12.8" (122 mm x 220 mm x 325 mm)
Channels	1					2
External Temperature Sensor Input (Sensor not Included)	-	-	-	-	Instantaneous Readout and Record Temperature Over Time	-
External Humidity Sensor Input (Sensor not Included)	-	-	-	-	Instantaneous Readout and Record Humidity Over Time	-
GPIO Ports	-			4, Programmable	4, Programmable	-
Source Spectral Correction	-	-	-			-
Attenuation Correction	-	-	-			-
External Trigger Input	-	-	-
Display
Type	Mechanical Needle and LCD Display with Digital Readout	320 x 240 Pixel Backlit Graphical LCD Display	No Built-In Display Controlled via GUI for PC	Resistive Touchscreen with Color Display	Protected Capacitive Touchscreen with Color Display	240 x 128 Pixels Graphical LCD Display
Dimensions	Digital: 1.9" x 0.5" (48.2 mm x 13.2 mm) Analog: 3.54" x 1.65" (90.0 mm x 42.0 mm)	3.17" x 2.36" (81.4 mm x 61.0 mm)	-	4.65" x 3.48" (118.0 mm x 88.5 mm)	3.7" x 2.1" (95 mm x 54 mm)	3.7" x 2.4" (94.0 mm x 61.0 mm)
Refresh Rate	20 Hz		Up to 500 Hz (PC Dependent)	100 Hz	10 Hz (Numerical) 25 Hz (Analog Simulation)	20 Hz
Measurement Viewsa
Numerical			Requires PCb
Mechanical Analog Needle		-	-	-	-	-
Simulated Analog Needle	-		Requires PCb
Bar Graph	-		Requires PCb
Trend Graph	-		Requires PCb
Histogram	-		Requires PCb	-	-
Statistics			Requires PCb
Memory
Type	-	SD Card	-	NAND Flash	NAND Flash	-
Size	-	2 GB	-	128 MB	4 GB	-
Power
Battery	LiPo 3.7 V 1300 mAh		-	LiPo 3.7 V 2600 mAh	LiPo 3.7 V 2600 mAh	-
External	5 VDC via USB or Included AC Adapter		5 VDC via USB	5 VDC via Included Power Supply	5 VDC via USB	Selectable Line Voltage: 100 V, 115 V, 230 V (±10%)
